In UK from June 2007. 4,581mm long by 1,770mm wide.
New C Class, looks a bit like the CLS with chassis improvements developed for the current SLK.
Was first car in its market segment to be awarded an Environmental Certificate. The certification body of TÜV Süd Management Service GmbH has confirmed the car’s environmentally focused development, highlighting advances over the entire vehicle lifecycle in areas such as fuel consumption, exhaust emissions and selection of materials. Meets requirements of internationally recognised ISO standard 14062. This standard, called ‘Design for Environment’, governs the integration of environmental aspects into product design and development.
Three model lines with the emphasis on a balance of comfort and an exhilarating driving experience: SE, Elegance or Sport. All model variants share Agility Control suspension package with selective damping, Pre-safe preventive occupant protection system and optional Intelligent Light System with five different lighting functions. Four and six-cylinder engines with improvements of up to 13 per cent more power output than the outgoing model, accompanied by up to six percent lower fuel consumption.
In the Elegance line there are chrome highlights on the radiator grille which is finished in high-gloss paint accentuating the brand attributes of comfort and luxury. The SE line offers the same technical innovations as the other two model variants. Both the Elegance and SE lines share a more executive and traditional-style front design, with a bonnet mounted Mercedes star.
Agility Control has selective damping, which controls the shock absorber forces according to the driving situation. It uses hydromechanics (rather than complicated electronics) to offer soft damping when low suspension forces are at work, when driving along a straight road, for example and much firmer damping action when high forces are applied; for example, when cornering or taking avoiding action.
Optional Advanced Agility package with a “sporty” driving mode, available from autumn 2007. This offers the driver a choice of two gearshift programmes: Sport and Comfort. Within these programmes the shock absorber for each wheel has infinitely variable electronic control. Adaptive Brake is another new development and is based on the technology of the S-Class. Include Hill Start Assist making it easier for the driver to move off on uphill gradients, priming the braking system in critical situations and light contact to dry the brake discs in wet conditions.
Output of the entry-level C 180 KOMPRESSOR increased to 156 hp (115 kW), with maximum torque 230 Nm. C 200 KOMPRESSOR develops 184 hp (135 kW) and generates maximum torque of 250 Nm from 2800 rpm.
New C 200 CDI has 136 hp (100 kW). C 220 CDI develops a peak output of 170 hp (125 kW) and generates a torque of 400 Nm from 2000 rpm. On New European Driving Cycle (NEDC), the C 200 CDI and C 220 CDI are able to travel 100 kilometres on just 6.1 litres of fuel.
V6-engines in the C-Class range remain unchanged, with a choice of three petrol units developing 204 hp (150 kW), 231 hp (170 kW) and 272 hp (200 kW). The six-cylinder C 320 CDI has a power output of 224 hp (165 kW). All four-cylinder engines and the six-cylinder C 230 come with standard six-speed manual gearbox. The C 280, C 350 and C 320 CDI have 7G-TRONIC as standard equipment. This is also available for the six-cylinder C 230 model as an option.
During the course of its development, the new C-Class Saloon successfully passed more than 100 crash tests, including the particularly demanding, in-house impact tests. Occupant protection is based on an intelligently designed bodyshell, 70 percent of which consists of high-strength and ultra high-strength steel. Mercedes-Benz has enlarged the deformation zones even further and improved energy flows. The front-end structure of the new C-Class has four independently acting impact levels, which enable forces to be distributed over a wide area while bypassing the passenger cell.
The safety technology in the interior has been complemented with the very latest protection systems. Seven airbags are included as standard equipment: two adaptive airbags for the driver and front passenger, a kneebag for the driver, two sidebags in the front seat backrests and two large windowbags which extend from the A to the C-pillar during a side impact. The driver, front passenger and the passengers on the outer rear seats also benefit from belt tensioners and belt force limiters as standard. The standard head restraints operate on the NECK PRO principle: during a rear-end collision the padded surfaces are pushed forward and upward within milliseconds to support the heads of the driver and front passenger at an early stage. This significantly reduces the risk of a whiplash injury.
Mercedes-Benz has developed flashing adaptive brake lights as a major help in reducing rear-end collisions, and these are also standard equipment in the new C-Class. If the driver needs to brake hard at speeds in excess of 30 mph the brake lights flash rapidly to warn drivers following behind. At higher speeds of around 70 mph, flashing lights make drivers react 0.2 seconds quicker than they do to conventional brake lights.
Pre-Safe is another innovative standard feature of the new Mercedes Saloon. This preventive occupant protection system is linked to active safety systems such as ESP and Brake Assist, and is able to recognise critical driving manoeuvres at a very early stage. If the C-Class is in danger of crashing as a result of heavy under or oversteering, or if the driver needs to brake very heavily in a dangerous situation, Pre-Safe activates certain systems as a precaution to prepare the vehicle and its occupants for an impending accident. Accordingly the passive safety phase does not begin when the impact has already occurred, but before an impending collision. If the impact is avoided Pre-Safe re-sets itself.
The Intelligent Light System developed by Mercedes-Benz is also available in this vehicle class as an option for the first time. Powerful bi-xenon headlamps are automatically adapted to the driving situation, illuminating a wider area when driving on country roads and improving long range visibility on motorways, for example. The system also includes enhanced front fog lamps, as well as the cornering light function and Active Light System, which enables the headlamps to follow steering input for better visibility. This is another important contribution by Mercedes-Benz to safer driving in poor visibility.
New control concept for clarity and comfort
The central colour display is part of the new control and display concept which the C-Class has adopted from the luxury-class Mercedes models. Its major advantage is rapid access to frequently used functions, which means that the driver does not need to relearn, is able to maintain familiar habits and feels at home immediately. All the control and display elements necessary and important during a journey are located in the cockpit, i.e. in immediate proximity to the driver.
In the same way, linking the standard, leather-trimmed multifunction steering wheel with the instrument cluster means rapid access to a wide range of information and functions in the driver’s direct line of vision. Other functions are shown on the display at the centre of the dashboard. The driver and front passenger are able to control the radio, navigation system or telephone by using the controller on the centre console, or access the main menus using direct selection keys.
The new C-Class features, as standard, the Audio 20 radio/CD system and optional integrated CD changer, Audio 50 APS and COMAND systems, which are newly developed, for C-Class passengers. They all feature a keypad for entering telephone numbers and radio frequencies, as well as a Bluetooth interface which wirelessly connects the Bluetooth mobile phone to the hands-free telephone system. In the Audio 50 APS, the route guidance information includes a visual display that automatically zooms in on junctions. A six-CD changer and the LINGUATRONIC voice control system are also integrated.
The multimedia system COMAND offers even more functions in the new C-Class. One new feature is a Europe-wide navigation system with data stored on a 30 Gigabyte hard disk. The high-resolution maps are shown on a colour display which pivots away and disappears beneath a cover at the touch of a button.
Other functions of COMAND include a music register with a four-Gigabyte memory, a DVD-player for video and audio, an integrated 6-disk CD/DVD changer, and the Linguatronic voice control system, which Mercedes-Benz has further improved. The driver no longer needs to spell out the names of countries, towns or roads, but is able to speak them as whole words. The voice control system is just as convenient when selecting radio stations or entries in the telephone directory. The C-Class is the bestseller in the Mercedes line-up
The new C-Class Saloon replaces a model series of which more than 1.4 million units have been sold worldwide since spring 2000. All in all, Mercedes-Benz has delivered more than two million of the Saloon, Estate and Sports Coupé models in the previous C-Class to customers all over the world. This makes the C-Class the bestseller in the Mercedes-Benz passenger car range. Since 2000, more than 114,000 C-Class Saloons have been registered in the UK, along with more than 23,000 C-Class Estate cars and more than 40,000 Sports Coupé models.
4-7-2007 457PS C63 AMG announced in the UK mid 2008
AMG 6.3-litre V8 engine develops a peak output of 457 hp and a maximum torque of 600 Nm – unrivalled figures in this segment. 0-60 mph in 4.3 seconds, top speed is electronically limited to 155 mph. In conjunction with an all-new front axle, speed-sensitive AMG sports steering and the new, three-stage ESP®, the AMG sports suspension ensures both outstanding driving enjoyment and exemplary handling dynamics. Market launch early 2008, with UK cars arriving mid 2008.
C63 AMG estate announced 6-9-2007. Maximum output 457 hp at 6,800 rpm, maximum torque of 600 Nm at 5000 rpm. Accelerates from 0 to 60 mph in 4.4 seconds; top speed is 155 mph (electronically limited). AMG SPEEDSHIFT PLUS 7G-TRONIC. Equipped with AMG steering wheel gearshift paddles and the three driving modes “C”, “S” and “M”, the seven-speed automatic transmission delivers a decidedly sporty or comfort-focused ride depending on the driver’s tastes. The automatic throttle-blipping function when downshifting is another innovation. In conjunction with the all-new front axle, the AMG speed-sensitive sports steering and the new 3-stage ESPÒ, the AMG sports suspension provides maximum driving pleasure and superb driving dynamics. The AMG high-performance braking system with large internally ventilated and perforated disc brakes all round provides optimum stopping power even during particularly dynamic driving. The standard specification includes 18-inch five-spoke AMG light-alloy wheels with 235/40 R 18 (front) and 255/35 R 18 (rear) wide-base tyres. 19-inch AMG multi-spoke light-alloy wheels shod with 235/35 R 19 (front) and 255/30 R 19 (rear) tyres are available as an option.
March 2008: Mercedes-Benz has concocted a BlueEFFICIENCY package for the four-cylinder C 180 KOMPRESSOR and C 200 CDI models which lowers fuel consumption by as much as 12%. Instead of the previous 46.3 mpg, the BlueEFFICIENCY version of the 100-kW/136-hp C 200 CDI now achieves 55.4 mpg. This equates to 135 grams of carbon dioxide per kilometre. In the case of the C 180 KOMPRESSOR Mercedes-Benz has reduced the engine\'s displacement from 1796 to 1597 cubic centimetres, but output (115 kW/156 hp) and torque (230 Newton metres) remain unchanged. It returns fuel consumption figures of 43.5 mpg, twelve per cent better than the figure for the standard production model.
A newly developed gearshift display in the cockpit informs the driver when he should change gear to save fuel. In addition to gearshift recommendations, the instrument cluster features a newly developed display showing the present fuel consumption.
March 2008: Also new C350 BlueEFFICIENCY with spray-guided direct injection at the Geneva Motor Show. This technology has previously been exclusive to just the CLS-Class and the E-Class, but is due to become available for the C-Class too from late 2008. Despite generating a higher power output and even greater torque, the new C350 CGI BlueEFFICIENCY consumes around ten per cent less fuel than the C350 saloon with the current V6 engine. This innovative new model is therefore set to offer a hitherto unrivalled combination of power delivery, agility, safety, economy and environmental compatibility in this vehicle class.
The CGI engine has an output of 215 kW/292 hp and 365Nm of peak torque at 3000 rpm, 15 kW/20 hp and 15Nm more respectively than the current V6 unit with port injection. Thanks to the state-of-the-art engine technology, fuel consumption of the C 350 CGI BlueEFFICIENCY has been cut to approx. 32.5 mpg (provisional NEDC figure). As such, the new six-cylinder engine makes a major contribution to reducing carbon dioxide emissions. These significantly improved output and fuel consumption figures are achieved whilst still using cost-efficient premium grade petrol (RON 95).
Euro NCAP 5 stars passenger protection, 3 stars child passenger protection, 2 stars pedestrian protection. Test results 18-12-2007.
Prices C 63 AMG saloon and estate announced 21-12-2007 for delivery Spring 2008. Saloon £51,317; Estate £52,567.
24-11-2008: Mercedes-Benz C 180 KOMPRESSOR BlueEFFICIENCY is ready to reduce motoring costs, emissions and tax implications for UK drivers. C180 KOMPRESSOR BlueEFFICIENCY replaces the existing model with no price increase
BlueEFFICIENCY is the name Mercedes-Benz has given to a range of measures to improve fuel economy and reduce CO2 emissions. The C 180 KOMPRESSOR BlueEFFICIENCY does just that, with weight saving measures, energy management and enhanced aerodynamics.
The C180 KOMPRESSOR BlueEFFICIENCY engine still offers 156hp and 230Nm of torque, despite a 199cc reduction in displacement. Fuel consumption has been improved by up to 11% with the manual saloon returning 44.8 mpg combined. This can be improved further by the driver as the C180 KOMPRESSOR BlueEFFICIENCY has a fuel economy indicator and Shift Point Indicator.
CO2 emissions have been reduced by an impressive 19 per cent now emitting just 149 g/km. The 18g/km reduction makes the C180 KOMPRESSOR BlueEFFICIENCY model an attractive choice for fleet managers as the CO2 improvements result in a shift from the 21 per cent tax band to the 17 per cent company car tax band. This will see savings of up to £30.90 a month and a yearly saving of £370.80 (based on 40 per cent taxpayer). Non-fleet customers also stand to benefit from the CO2 reduction as the model moves from road fund licence band E to C creating a £50 saving.
Part of this emissions improvement has been thanks to the 195/60 low rolling-resistance tyres that will be fitted to SE saloon models as standard. New, smaller exterior mirrors improve the aerodynamics of the car and feature the new LED arrow shaped indicator lens also featured on new-generation models launched earlier this year. Another advantage of the new BlueEFFICIENCY C-Class model is the efficient energy management system which only activates power-assisted steering when it is needed.
2-7-2010: Exclusive new C-Class DR 520 with more power and performance than any other C-Class. Only 20 units of this car available, sold exclusively through Specialist Products division at Mercedes-Benz World at Brooklands, Surrey.
Based on the high-performance C 63 AMG, the DR 520 has a performance upgrade and boasts 520 hp and 650 Nm of torque, a 60 hp and 50 Nm advantage over than the standard C 63 AMG. The DR 520 Saloon can reach 0-62 mph in just 4.1 seconds with the Estate achieving the same in 4.2 seconds, and both are electronically limited to a top speed of 187 mph.
The AMG Performance Pack Plus is fitted to the DR 520 as standard and features AMG’s high-performance braking system with red calipers, with the addition of engine upgrades in the form of forged pistons, newly-developed connecting rods and a revised crankshaft, as well as an AMG Carbon Fibre rear spoiler for the Saloon. Available with a black or white matt wrap and complimented by Titanium finish alloy wheels, grille and discreet DR 520 badging on the wing and the boot lid, the DR 520 combines stealthy looks with potent performance.
Inside, the sports seats are upholstered in leather and exclusive Alcantara finished with red or white contrast stitching, as is the dashboard and upper door panels. The multi-function AMG Performance steering wheel is clad in Nappa leather and Alcantara. The DR 520 costs £9,995 above the standard C 63 AMG price, making the DR 520 Saloon £62,430 OTR and the Estate £63,680 OTR. The cars are also backed by a three-year, 60,000 mileage warranty.
23-12-2010: C-Class heavily revised from March 2011:
The revised C-Class will be launched in spring 2011 and is a comprehensive modernisation. The front and rear sections of this best selling model have a more striking design. There is now a high-resolution colour display screen in the instrument cluster, an elegant new dashboard with grained surface and prominent decorative trim emphasising the premium character of the interior. Fuel consumption has been improved by up to 31 per cent. Efficiency-enhancing measures including new engines, the improved 7G-TRONIC PLUS automatic transmission and the ECO start/stop function also feature. Ten new driving assistance systems ranging from the standard ATTENTION ASSIST drowsiness detection system to the optional DISTRONIC PLUS proximity control system are also now available for this model series for the first time.
"In terms of drive and protection systems the new-generation C-Class offers the same comfort and safety as our luxury models. High-grade interior features remind one of the new CLS, the C-Class sets completely new standards in its segment with respect to perceived value and quality," says Dr. Joachim Schmidt, Sales & Marketing Director at Mercedes-Benz Cars. This interior modernisation is supplemented with a new telematics generation that not only includes completely redesigned displays, but also makes onboard internet access available.
A total of more than 2,000 new components distinguish the latest generation of the Mercedes-Benz C-Class from its predecessor. The UK market launch of the Saloon and Estate versions will take place in March 2011.
The C-Class is the highest-selling model series for Mercedes-Benz. The current series has found well over one million buyers worldwide since its launch in March 2007 (98,000 UK sales). Since the introduction of the first C-Class in 1982 (then known as the model 190), Mercedes-Benz has sold more than 8.5 million vehicles in total in this segment. In 2010 too, the C-Class has repeatedly won top places in the registration statistics.
Dynamic, resolute, self-assured: the exterior
The front bumper has more expressive and dynamic contours, with the front section being brought in line with the brand's new design idiom. The radiator grille surround is now more prominent. The central air intake opens out upwards in a V-shape, forming a visual base unit for the radiator grille. Pronounced side sections extend from the sporty V-shape at the centre of the bumper. Continuing beneath the headlamps, these sections blend into the feature lines along the vehicle flanks, linking the front section with the sides. The side air inlets in the bumper are positioned low down, giving the car a more road-hugging appearance.
The Saloon and Estate now have a new aluminium bonnet, which contributes to weight reduction and therefore enhances fuel efficiency. Its contour in the area of the headlamps and radiator grille emphasises the V-shape of the front section more heavily than before. In conjunction with the newly designed headlamps, this gives the front section a more resolute impression.
The shape of the clear-lens headlamps has been modified to create a more dynamic and resolute impression, and to act together with the bonnet, radiator grille and bumper to emphasise the V-shape of the front section. This impression is reinforced by both the exterior form of the headlamps and the interior of the housings. The headlamps show their modernity by precision and an interplay between matt and high-sheen areas. The halogen headlamps are arranged in the classic way, with low beam on the outside, high beam on the inside and the indicators neatly arranged in the outer corner formed with the front wing.
If the optional bi-xenon headlamps with the Intelligent Light System (ILS) are specified, the impression of depth is reinforced by a row of lighting modules. A position light with a distinctive C-shape emphasises the night design. Behind it is a cornering light extending to the main headlamp module on the outside. All three levels are connected by a transverse strip extending through the complete headlamp interior with dark contrasts, shiny areas and matt areas. A visual base in the lower section of the headlamp is formed by a horizontal broadband LED indicator unit. The horizontal LED daytime running lamps in the bumper also make the C-Class unmistakable from a distance.
In the case of the rear bumper, the light-catching contours and dividing lines have been modified to emphasise the width of the Saloon and Estate even more strongly. This change is particularly obvious in the more steeply rising course of the side light-catching contours towards the tail lights. A continuous light-catching contour at the upper end of the rear bumper extends into the flanks to connect the rear end with the sides to emphasise the sporty character of the rear aspect. In the latest model, the tail lights are even more neatly integrated into the rear section by a continuous covering lens. The characteristic surface meander is now on the inside of the light, and reminiscent of preceding model series. The particular impression of depth is achieved by a centrally located LED indicator, which appears to float in front of the red upper and lower light bands with their more deeply set LEDs. The tail lights have a particularly high recognition factor in the dark.
The aerodynamics of the C-Class are a mark of the bodyshell's efficiency. With a Cd figure of 0.26 it not only sets the benchmark in its class, but also glides through the wind better than most compact cars with its drag area of Cd x A = 0.57 sq. m.
Sporty, high-quality interior
The main focus of the design work in the interior was on restyling the dashboard with its integrated screen and new surface grain. The touch surfaces of the controls are now also more finely detailed and galvanised. A stepped extension to the instrument cluster now also accommodates the central display. The instrument cluster and a discreet light-catching contour continue into the front passenger side while the central, trapezoidal air vents and the round vents on the outside are highlighted in detail by galvanised trim.
The large section of trim is an important part of the newly designed dashboard. This extends from the centre air vents across the front passenger side to the outer air vent, while the lower edge of the upper dashboard section continues into the beltlines of the door panels with a new surface grain.
The control panel of the new-generation communication and information unit has keys with high-gloss surface inserts. The combination of keys, high-gloss areas and a new knurled wheel design accentuates the enhanced interior. In conjunction with the new generation telematics generation, the C-Class is now available with a high-resolution colour display in the instrument cluster.
More power, lower consumption: the engines
An improvement of up to 31 per cent has been achieved in fuel consumption and all C-Class launch models will feature the ECO start/stop function as standard. All the engine variants are now classed as BlueEFFICIENCY units, showing that they are particularly efficient and environmentally compatible in their use of fuel. In future all automatic versions will feature the further-developed 7G-TRONIC PLUS
seven-speed automatic transmission. In addition, the overall ratio of all new powertrain variants has been optimised for better fuel economy.
All the petrol engines in the model series have direct injection. One of the highlights is the introduction of the new V6 petrol engine with its innovative and highly efficient BlueDIRECT process in the C 350 BlueEFFICIENCY. The quantum leap in efficiency is particularly well illustrated by the six-cylinder
unit: Power has increased considerably, the C 350 BlueEFFICIENCY delivering 306 hp and 370 Nm (previously 292 hp and 365 Nm).
The four-cylinder petrol engines, which made a great evolutionary leap forward
in 2009 and all feature direct injection and turbocharging and excel with high performance and exemplary economy.
All C-Class petrol models at a glance
|C 180 BE||4/in-line||1796||156
|C 250 BE||4/in-line||1796||204
|C 350 BE||V6||3498||306
BE = BlueEFFICIENCY, * figures for automatic transmission, manual transmission in brackets
The most economical model in the Mercedes C-Class range has also become even more frugal: the C 220 CDI BlueEFFICIENCY with the manual six-speed transmission and the standard ECO start/stop function. This corresponds to 117 grams of CO2 per kilometre. In conjunction with the improved 7G-TRONIC PLUS automatic transmission and the ECO start/stop function included as standard, the C 220 CDI BlueEFFICIENCY and C 250 CDI BlueEFFICIENCY both deliver
top-class figures with a combined diesel consumption of 58.8 mpg. This corresponds to CO2 emissions of 125 grams per kilometre.
All C-Class diesel models at a glance
|C 200 CDI BE||4/in-line||2143||136
|C 220 CDI BE||4/in-line||2143||170
|C 250 CDI BE||4/in-line||2143||204
BE = BlueEFFICIENCY, * figures for automatic transmission, manual transmission in brackets
Warning and intervening: the new driving assistance systems
With a total of ten new driving assistance systems ranging from ATTENTION ASSIST drowsiness detection to DISTRONIC PLUS proximity control, the C-Class reaches a new level in safety. The assistance systems are based on the latest radar, camera and sensor technology, and cover frequent accident causes such as driving too closely, fatigue and darkness. The new assistance systems, some of which only warn and some which actively intervene in hazardous situations, at a glance:
- Adaptive Highbeam Assist
- Active Lane Keeping Assist
- Active Blind Spot Assist
- ATTENTION ASSIST
- DISTRONIC PLUS
- Speed Limit Assist
- Parking guidance including PARKTRONIC
- Lane Keeping Assist
- Blind Spot Assist
More operating comfort, better connectivity: new-generation telematics
The new C-Class also sees the debut of a new telematics generation which will also be gradually introduced in other model series. Major new features include greater operating convenience, larger displays, telephone directory transfer, display of SMS messages, wireless music reproduction via Bluetooth and a USB interface now accommodated in the centre armrest.
The multimedia system COMAND Online now provides internet access for the first time (via the customers data enabled mobile phone). When the car is stationary, customers are able to browse freely or surf to a Mercedes-Benz Online service whose pages load particularly rapidly and are also easy to use while on the move. The integrated services include weather information and a special destination search via Google, as well as the option of downloading a route that has been previously configured on a PC using Google Maps and sent to the car. The navigation system of COMAND Online also has added functions.
Also new: routes covered can be recorded and repeated later, specific personal destinations can be imported via an SD card and four alternative routes can be displayed on the navigation map, one of them a particularly economical variation.
As a first in the C-Class, the Becker® MAP PILOT makes a low-cost navigation function, which can also be retrofitted, available for the entry-level Audio 20 CD radio. Its advantages over aftermarket solutions include integrated operation via the central controls and the Audio 20 display, a concealed location in the glove compartment and updating via an internet portal.
2-2-2011: New C63 AMG
The latest 2011 generation of the C63 AMGis now more dynamic and athletic. Thanks to its new radiator grille with a large Mercedes star and a wing-type transverse louvre, as well as a new AMG front apron with a lower cross member painted in high-gloss black, special AMG daytime running lights and side air outlets, the front section recalls the look of the SL 63 AMG high-performance roadster. The new bonnet with its modified powerdomes is now made of aluminium. New clear-lens headlamps emphasise the car's distinctive, self-confident presence and the Intelligent Light System (ILS) is fitted as standard. The wide front wings with the "6.3 AMG" legend and the new 5 twin-spoke AMG light-alloy wheels which are painted in titanium grey and have a high-sheen finish dominate the side view. Good contact with the road is provided by the wide 235/40 R 18 and 255/35 R 18 tyres at front and rear respectively.
The rear view of the C 63 AMGalso evokes the SL 63 AMG: the new AMG rear apron has a distinctive, black diffuser insert with three pronounced diffuser fins. The two chromed twin tailpipes of the AMG sports exhaust system are as pleasing to the ear as they are to the eye.
AMGSPEEDSHIFT MCT 7-speed sports transmission from the SL 63 AMG
The new C63 AMG model boasts a wealth of new technology including the AMGSPEEDSHIFT MCT 7-speed sports transmission. Rather than using a torque converter, this innovative transmission has a wet start-off clutch which allows it to deliver a much more efficient, agile and direct response. Fuel consumption and emissions have been reduced significantly thanks to the "Comfort" mode and a new power steering pump: at 23.5 mpg (Estate: 22.9 mpg) the combined NEDC fuel consumption of the C 63 AMG sees about a ten per cent improvement over that of the previous model. CO2 emissions figure is now 280 (Estate: 288) grams per kilometre. Both power variants have identical fuel consumption and emission figures.
The AMGSPEEDSHIFT MCT 7-speed sports transmission offers four driving modes as well as double-declutching and RACE START functions it is as compatible with a relaxed, fuel-saving driving style as it is with high-speed laps on a closed racing circuit and extremely dynamic overtaking manoeuvres. The Comfort "C" mode is programmed to provide early, comfortable upshifts while maintaining the lowest possible engine speed to help the driver keep fuel consumption down. The "S", "S+" and "M" modes deliver increased agility through fast, responsive gear changes and higher revs. Gear changes in the "S+" and "M" modes take just 100 milliseconds.
The naturally aspirated eight-cylinder engine with its large displacement of 6208 cc develops 457 hp at 6800 rpm and attains a peak torque of 600 newton metres at 5000 rpm (the C63 does NOT get the 5.5 litre 525PS twin turbo C63 V8). A look at the performance figures confirms that the new C63 AMG retains its predecessor's position as the top performing model in its segment: acceleration from standstill to 62 mph in just 4.5 seconds (Estate: 4.6 s) while the top speed is 155 mph (electronically limited).
Performance package: technology transfer from the SLS AMG
Even more dynamic performance is available with the optional AMG Performance package: this offers 487 hp and allows a 0-62 mph acceleration time of 4.4 seconds (Estate: 4.5 s). The Mercedes-AMG engine experts have achieved this increase in output thanks to a technology transfer from the SLS AMG: the forged pistons, connecting rods and the lightweight crankshaft all come from the gullwing model's engine. The reduced mass inertia of the components – which are three kilograms lighter than those of the standard version – allows the naturally aspirated eight-cylinder engine to rev up with even greater ease and agility. Models equipped with the performance package can be identified by the variable intake manifold painted in titanium grey under the bonnet, the AMG high-performance braking system with composite front discs and red painted brake callipers all round, the carbon-fibre spoiler lip on the boot lid (Saloon) and the AMG performance steering wheel in nappa leather with an Alcantara® grip area.
|C 63 AMG||C 63AMGEstate|
|Displacement||6208 cc||6208 cc|
|Bore x stroke||102.2 x 94.6 mm||102.2 x 94.6 mm|
|Compression ratio||11.3 : 1||11.3 : 1|
|Output||457 hp at 6800 rpm
487 hp at 6800 rpm*
|457 hp at 6800 rpm
487 hp at 6800 rpm*
|Max. torque||600 Nm at 5000 rpm||600 Nm at 5000 rpm|
|Engine weight (dry)||196 kg||196 kg|
|Fuel consumption - combined, mpg||23.5 mpg||22.9 mpg|
|CO2 emissions||280 g/km||288 g/km|
Acceleration 0 – 62 mph
|Top speed**||155 mph**||155 mph**|
Key data at a glance:
* with AMG Performance package; ** electronically limited
Optimised suspension, new steering system reduces fuel consumption
TheAMGsports suspension with a special front axle, reinforced rear axle and wider track all round has undergone thorough modification; the driver benefits from this in two ways as the C 63 AMG now offers greater driving enjoyment and ride comfort at all times. The new, stiffer elastokinematics, the revised axle kinematics with more negative camber all round and the new rear-axle anti-roll bar with a larger cross-section result in higher agility and greater lateral acceleration. But driving dynamics is not the only area in which progress has been made: new spring and damper rates have optimised both the responsiveness of the suspension as well as the road roar and tyre vibration characteristics.
The AMGspeed-sensitive sports steering with a direct ratio (13.5 : 1) has a newly developed power-steering pump which plays a decisive role in reducing the fuel consumption. This is because the power assistance for the steering only requires energy when the driver is actually making steering movements. Reliable deceleration at all times is ensured by the AMG high-performance braking
system with internally ventilated and perforated discs all round.
Interior: high quality and perceived value
The completely new dashboard design with an integrated screen impresses with its particularly attractive appearance and the superior quality of the details which immediately bring the new CLS 63 AMG to mind. The new, all-colour, three-dimensional TFT display in the middle of the redesigned speedometer welcomes the driver by showing the AMG logo. The new three-spoke AMG performance steering wheel - another feature adopted from the CLS 63 AMG – which is trimmed in nappa leather and features a metallic trim element has flattened top and bottom sections as well as grip areas which are specially shaped and trimmed in perforated leather for perfect steering control. Aluminium shift paddles allow manual gear selection.
Fine trim elements in brushed dark aluminium are to be found on the dashboard and doors. Situated in the centre console, is the enhanced high-gloss black piano lacquer trim elements and the new rotary control for selecting the transmission modes C, S, S+, M and RACESTART. The special AMG sports seats with integral head restraints and adaptive backrests are upholstered in nappa leather.
Other attractive optional appointments are also exclusively available for the C 63 AMGfrom the AMG Performance Studio:
- AMGfive-spoke light-alloy wheels, painted in titanium grey with a high-gloss finish, with 235/40 R 18 (front) and 255/35 R 18 (rear) tyres
- AMGmulti-spoke light-alloy wheels, painted in titanium grey with a high-gloss finish, with 235/35 R 19 (front) and 255/30 R 19 (rear) tyres
- AMGmulti-spoke light-alloy wheels, painted in matt black with a high-gloss finish on the rim flange, with 235/35 R 19 (front) and 255/30 R 19 (rear) tyres
- AMGExterior Carbon-Fibre package
- AMGrear axle differential lock
- AMGtrim elements in carbon fibre/high-gloss black piano lacquer
- Illuminated AMGdoor sill panels
Eleven new driving assistance systems already established in the S-Class and CLS
The C 63 AMGfeatures eleven new driving assistance systems which are already established in the S-Class flagship range and the trend-setting CLS. These assistance systems use the latest radar, camera and sensor technology and are designed to combat common causes of accidents, such as insufficient distance to the vehicle ahead, drowsiness and darkness. They raise the safety standard of the C-Class to a new level by warning the driver of a hazard, or, if necessary, taking active corrective measures.
- Adaptive Highbeam Assist - standard
- Active Lane Keeping Assist - optional
- Active Blind Spot Assist – optional
- ATTENTION ASSIST – standard
- DISTRONIC PLUS – optional
- Speed Limit Assist – optional
- PARKTRONIC including parking guidance - standard
- PRE-SAFE® Brake- optional
- Reversing camera – optional
- Lane Keeping Assist – optional
- Blind Spot Assist – optional
New generation of telematics is the first to feature internet access
The C-Class sees the debut of a new telematics generation which will also be gradually introduced in other model series. Major new features include greater operating convenience, larger displays, telephone directory transfer via Bluetooth®, wireless music reproduction and a USB interface in the centre console.
The top-of-the-range COMAND Online system now provides internet access for the first time. When the car is stationary the customer can browse freely or surf to a Mercedes-Benz Online service whose pages load particularly rapidly. The integrated services include weather information and a local search function as well as the option of downloading a route that has been previously configured on a PC using Google maps and sent to the car. The navigation system of COMAND Online also has added functions. New features include a 3D display with virtual city views. Also new: routes covered can be recorded and repeated later, specific personal destinations can be entered and stored and three alternative routes can be displayed on the screen - one of them a particularly economical variant.
As a first in the C-Class, the Becker MAP PILOT makes a low-cost navigation function,. Its advantages over aftermarket solutions include integrated operation via the Central Controller dial and the Audio 20 display. (Let's hope it accepts 7 digit UK postcodes.)
C 63 AMG – fast-track to best-seller status
Launched in summer 2007, the Mercedes-Benz C63 AMGrapidly established itself as a real best-seller in the AMG model range. Customers all over the world appreciated this unique combination of a powerful and torquey naturally aspirated eight-cylinder engine, a distinctive sound, an agile sports suspension and expressive design. Over the past three and a half years more than 17,000 AMG enthusiasts have chosen the C 63 AMG, 88 percent of them opting for the Saloon (Estate: 12 percent). The AMG Performance package, which has been available since autumn 2009, is proving particularly popular: over 30 percent of all the C 63 AMG models delivered in 2010 were specified with this attractive option.
30-07-12: Mercedes-Benz revealed a series of upgrades to the 2013 C-Class range. The enhancements help to lower running costs and can reduce BIK for business drivers by up to four per cent, giving the C-Class an even greater competitive advantage over premium compact rivals. In addition, the revisions have immediately had a positive impact on the already-strong residual values of the C-Class, with CAP announcing a five per cent (£450) increase in values for the entry-level trim grade.
Executive SE is the new entry point to the revised range for the C 180 BlueEFFICIENCY, C 200 CDI BlueEFFICIENCY and C 220 CDI BlueEFFICIENCY Saloon and Estate, which includes a sports grille, new 16-inch alloy wheels, Artico upholstery and LED daytime running lights at a price increase of only £35 over the previous SE grade.
A new Luxury Package is available for Executive SE models to replace the former Elegance trim option. Carrying a £2,000 premium, it includes the three louver grille with bonnet-mounted star, 17” alloy wheels with a seven twin-spoke design, automatically dimming rear view mirror and folding exterior door mirrors, chrome trim on the side, rear and shoulder line, a storage package and brown Ash wood trim with a matt finish.
The Sport trim makes way in the 2013 C-Class for two new variants –AMG Sport and AMG Sport Plus. The AMG Sport Saloon and Estate cost £960 less than the previous Sport models, and feature 17-inch AMG wheels and halogen headlights.
In addition, there is a tax saving on the new AMG Sport, thanks to a reduction in CO2 over the previous model. For example, the previous C 220 CDI Sport Saloon with manual transmission offered 133g CO2/km and BIK 2012/13 of 20%, giving a total BIK over 36 months of £7,865, based on an income tax bracket of 40%.
By comparison, the new C 220 CDI BlueEFFICIENCY AMG Sport Saloon with manual transmission gives 123g CO2/km and BIK 2012/13 of 18%. Therefore the total BIK over 36 months is £6,897, giving a total saving of £968.
AMG Sport Plus
The AMG Sport Plus, priced £1,000 above AMG Sport and just £35 over the previous Sport line, includes 18-inch bi-colour AMG alloys, bi-Xenon front lights with Intelligent Light System and Adaptive High Beam Assist, AMG sports seats, Black Artico/Dinamica upholstery with contrast red stitching, red seat belts, AMG floor mats with red edging and silver gearshift paddles (automatic transmission only).
In the C-Class Coupé, the pricing and specification of the AMG Sport are unchanged, but an AMG Sport Plus version is now available for an additional £1,000. The comprehensive list of trim additions includes 18-inch bi-colour AMG alloys, an AMG boot lip spoiler in body colour, AMG sports seats, Black Artico/Dynamica upholstery with the contrast red stitching on the seats and door panels, red seat belts, AMG floor mats with red edging and silver gearshift paddles (automatic transmission only).
A £530 AMG Handling Package is offered on the C-Class Coupé to uprate the steering, engine, exhaust and transmission response, as well as introducing unique styling touches. The Dynamic Handling Package continues to be available on selected Saloon and Estate models.
The C 180 BlueEFFICIENCY is powered by a new ultra-efficient 1.6-litre direct-injection turbocharged petrol engine and is accompanied by electric power steering to further bolster economy.
With an output of 154 hp at 5,000 rpm, the new engine is almost as powerful as its predecessor while developing an identical 250 Nm of torque across a wider rev range – 1,250 to 4,000 rpm.
- C 180 BlueEFFICIENCY Saloon returns 47.9 mpg and 138 g CO2/km
- C 180 BlueEFFICIENCY Estate returns 47.9 mpg and 139 g CO2/km
- C 180 BlueEFFICIENCY Coupé returns 44.1 mpg and 149 g CO2/km
While the 3.5-litre V6 petrol engine is no longer offered in the C-Class Saloon and Estate, it is still available in the C-Class Coupé. In addition, the C 63 AMG performance models remain unaffected by the 2013 model year revisions.
Interior and exterior features
There are also new interior and exterior features, including revised colour options, repositioned cruise control and indicator stalks and easier-to-read silver graphics for the telematics screen. The telematics system in conjunction with Mercedes-Benz COMAND now includes eCall to report the car’s position to a call centre via GPS in the event of an emergency.
16-1-2013: On post 2012 facelift C-Class the COMAND satnav accepts 7 figure Post-Codes.
